BCM – Blood Collection Module
Description
The Blood Collecting Module is built for blood collection, processing, and storage. BCM’s sturdy shell and three-level backup system will ensure storage conditions of -80°c to +25°c, assuming an outside temperature from -40°c up to +50°c. BCM can preserve these storage conditions up to 36h without an external electric or diesel power source. The storage conditions are remotely observable via computer.
Specification
| Gross weight: | 12 000 kg |
| Load capacity: | 6 000 kg |
| Dimensions according to ISO668: | 1CC (20ft) |
| Total length: | 6058 mm |
| Height: | 2591 mm |
| Width in transport: | 2438 mm |
| Width when opened: | 4617 mm |
| Insulation: | 50 mm XPS |
| Floor area when expanded: | ~25 m2 |
| Standards: | ISO 1161: 2016, ISO 1496-1-5: 2013, CSC Certificated |
| Operating temperature: | from -40°C to +50°C |
| Deployment and repack time: | 10 minutes |
| Equipment: | 10kW generator, Blood collecting chair, Medical workstation, Freezer (down to -65°c), Refrigerator (+1 - +6 °c), POC labratory, Workstation with laptop PC, Air conditioning, Electrical and diesel heating |
